　　bulk heli-foil™ultra low loss,flexible microwave coaxial cable and a full range of passivated stainless steel connectors are now available for self assembly.covering the dc-18 ghz frequency,heli-foil cable comes in three different diameters,with options of stranded center conductors(for dynamic applications)and solid center conductors(for static applications).all sizes provide state of the art lowest insertion loss and excellent phase stability.

　　heli-foil assemblies are used for general applications in both field and laboratory conditions.they are ideally suited for high ambient temperature environments,such as communication systems’internal interconnects.

　　features&benefits:

　　•dc-18 ghz do it yourself cable assemblies

　　•lowest insertion loss available,dc-18ghz

　　•ultra stable insertion loss,phase and vswr

　　with flexing

　　•excellent phase tracking performance with

　　wide temperature(-55°c to+150°c)

　　•extremely flexible,low minimum bend radius

　　•superior shielding effectiveness(>100 db)
